Skytron Central Mount Carrier Arms

Skytron Central Mount Carrier Arms

Skytron’s central mount carrier arms feature one dual arm set and up to two light heads from a single ceiling-mounted hub. Contact us for your quote.

Product Inquiry
Log In for Pricing

Skytron’s central mount carrier arms feature one dual arm set and up to two light heads from a single ceiling-mounted hub

Download Product Brochure



Skytron central mount carrier arms are simple and cost-effective solutions, ideal for healthcare facilities looking to supplement their lights with simple accessibility to equipment, medical gases and utilities.

In addition, this configuration allows the equipment carrier to be positioned anywhere around the patient without affecting light placement, thus bringing you a level of flexibility unlike any other option in today’s market.

All models are available as either standard or heavy-duty.

KEY FEATURES

  • Upper Arm = 61” (standard), 51” (HD)
  • Lower Arm = 31.5”
  • Supports multiple carrier styles and flat screen mounts
  • Friction braking system reduces maintenance costs
  • HD models feature increased weight capacity
  • Powered, fixed or manual height adjustment
  • Available with or without lights



ModelDescriptionHeightLightsUpper
Arm
Lower
Arm
Additional Notes
415-0000-0039EC2F_/Lights: Central mount with dual arm systemfixed on one hubYes61"31.5"
415-0000-0032EC2E_/Lights: Central mount with dual arm systempowered on one hubYes61"31.5"
415-0000-0044EC2S_/Lights: Central mount with dual arm systemmanual on one hubYes61"31.5"UB, VB or FC3 carriers only
415-0000-0040EC2F_/NL: Central mount with dual arm systemfixed on one hubNo61"31.5"
415-0000-0033EC2E_/NL: Central mount with dual arm systempowered on one hubNo61"31.5"
415-0000-0045EC2S_/NL: Central mount with dual arm systemmanual on one hubNo61"31.5"UB, VB or FC3 carriers only
415-0000-0042EC2F-C_/Lights: Heavy duty central mount arm systemfixed on one hubYes51"31.5"
415-0000-0035EC2E-C_/Lights: Heavy duty central mount arm systempowered on one hubYes51"31.5"
415-0000-0047EC2S-C_/Lights: Heavy duty central mount arm systemmanual on one hubYes51"31.5"UB or VB carriers only
415-0000-0037EC2E-CD_/Lights: Heavy duty central mount arm systempowered on one hub with Dock-It headYes51"31.5"
EC2E-CDK/LightsHeavy duty central mount arm systempowered on one hub with Dock-It headYes51"31.5"16.5” wide carrier
415-0000-0043EC2F-C_/NL: Heavy duty central mount arm systemfixed on one hubNo51"31.5"
415-0000-0048EC2S-C_/NL: Heavy duty central mount arm systemmanual on one hubNo51"31.5"UB or VB carriers only
415-0000-0038EC2E-CD_/NL: Heavy duty central mount arm systempowered on one hub with Dock-It headNo51"31.5"
EC2E-CDK/NLHeavy duty central mount arm systempowered on one hub with Dock-It headNo51"31.5"16.5” wide carrier
415-0000-0034EC2E_W_: Central mount with dual arm systempowered on one hub61" 31.5"With adapter for Stellar Flatscreen System
415-0000-0036EC2E-C_/NL: Heavy duty central mount arm systempowered on one hubNo51"31.5"
415-0000-0041EC2F_W_: Central mount with dual arm systemfixed on one hub61"31.5"With adapter for Stellar Flatscreen System
415-0000-0046EC2S_W_: Central mount with dual arm systemmanual on one hub61"31.5"With adapter for Stellar Flatscreen System (UB or VB carriers only)
